高温化学非平衡与表面微孔隙效应对边界层稳定性影响

CSTR: 32037.14.aps.74.20250269

Influence of high-temperature chemical non-equilibrium and surface micropore effect on boundary layer stability

CSTR: 32037.14.aps.74.20250269
PDF
PDF English Version
HTML
导出引用
  • 层流-湍流的转捩问题是飞行器设计研制面临的重要气动难题. 当飞行马赫数较高时, 飞行器表面同时存在高温气体热化学反应与微孔隙效应, 此时边界层失稳问题更加复杂, 其机理认识尚不清楚. 本文建立了同时考虑高温化学非平衡效应和表面微孔隙效应的线性稳定性分析方法, 并针对高空H = 25 km、马赫数10, 15和20的飞行工况, 对比分析了化学非平衡效应、微孔隙效应以及两种效应共存时对流动稳定性的影响. 研究发现, 化学非平衡效应能够促进边界层模态失稳, 微孔隙效应能够抑制第二模态失稳, 前者作用强于后者, 导致两者共存时整体上促进第二模态失稳. 化学非平衡效应能够降低孔隙效应抑制第二模态对应的频率范围, 造成在局部低频范围内化学非平衡效应可以增强微孔隙效应的抑制效果, 而在高频范围内减弱其抑制效果, 导致孔隙效应N值降低量整体上减小. 此外, 两种效应共存时马赫数变化对微孔隙效应抑制第二模态的能力影响不大.



    The transition from laminar to turbulent flow is one of the main aerodynamic challenges in aircraft design and development. When the flight Mach number is sufficiently high, the aircraft surface experiences micropore effects and high-temperature gas thermochemical reactions. At present, boundary layer instability has become a more complex problem, and its mechanism is still unclear. In this study, a linear stability analysis method is developed which takes into consideration high-temperature chemical non-equilibrium process and surface micropore effect. For flight conditions at high altitude (H = 25 km) with Mach numbers 10, 15, and 20, the effects of micropore effects, chemical non-equilibrium effects, and their joint effect on flow stability are contrasted and investigated. The results show that the chemical non-equilibrium effect can contribute to the boundary layer's mode instability, while the micropore effect can restrain the second mode instability. The coexistence of the two often contributes to the instability of the second mode, because the former is heavier than the latter. The chemical non-equilibrium effect can reduce the frequency range corresponding to the second mode of pore effect inhibition, which results in the chemical non-equilibrium effect enhancing the inhibition effect of the micropore effect in the local low-frequency range and weakening its inhibition effect in the high-frequency range. This, in turn, causes a decrease in the corresponding N value variation by pore effect. Furthermore, when both effects are present, the micropore effect’s capacity to inhibit the second mode is not significantly affected by change in Mach number.
